Stem & Housing Material : Brass
Float Material: 316 SS
1″ NPT Mount
4100 Series – Side Mounted Level Switches
$740.00 Excl. GST
All prices are in NZ$, and GST exclusive and are subject to change without notice.
Technical Specs
| 4100 Series Specifications | ||
| Stem & Housing Material | Brass | |
| Float Material | 316 SS | |
| Mounting | 1" NPT; Side Tank Mount | |
| Reed Switch | 20VA SPDT | |
| Operating Temperature | -34~150°C | |
| Weight | 1.5 lbs | 1.5 lbs |
| Dimensions | 12×7×8in | 12×7×8in |
| Operating pressure | 62 bar max (2" Spherical) or 69 bar max (1" Cylindrical) | 62 bar max (2" Spherical) or 69 bar max (1" Cylindrical) |
| Specific Gravity | 0.8 (Model 4100-24221) and 0.7 (model 4100-24227) |
